DMX LED Controllers

SolidApollo's DMX 512 Controllers offer high end control systems for any type of DMX512 enabled LED Lighting Device. DMX is a communication protocol which enables the control of endless DMX enabled devises through a single control line, making installations and control very simple.Functions may vary on each model, but basically here are some of the most used functions:

  • Individual Control of many zones.
  • Do you have a big LED lighting project and you wish to control several zones from a single control unit?
  • Do you want to automate lighting sequences with timing, color control, and brightness levels?
  • Do you need to create special LED Lighting effects that are not possible in basic LED lighting control systems?

If your answer is YES, then DMX is the solution for you.

Products

Duet 3 Zone DMX & Wireless RGB-W In-Wall Controller
Duet 3 Zone DMX & Wireless RGB-W In-Wall Controller
SKU: SA-CTRL-DMX-DUET-3ZONE
  • 3 Zone Lighting Control
  • Amazing 3 in 1 Controller: DMX Control, Wireless RGB-W or Both Simultaneously
  • 10 Exciting Color Changing Programs
  • Simple Color Touch Wheel
  • Modern Touch Sensitive Surface
  • Fits Standard US Gang Boxes
  • 50 Foot Wireless Range
  • Built In Memory – Remembers Last Setting Even When the Power Goes Off
QTY Price per unit
1-4 $109.00
5-10 $104.00
11+ $98.00
Duet DMX & Wireless RGB-W In-Wall Controller
Duet DMX & Wireless RGB-W In-Wall Controller
SKU: SA-CTRL-DMX-GLASS
  • 2 in 1 Controller: DMX Control or Wireless RGB-W
  • Includes 10 Pre-loaded Programs
  • Full Color Options, Dimming and Speed Control
  • Touch Sensitive Glass Surface
  • Easily Fits Standard US Switch Boxes
  • 50 Foot Wireless Range
  • Memory Function – Remembers Last Setting Even When the Power Goes Off
  • Perfect for Controlling DMX or RGB-W Fixtures
QTY Price per unit
1-4 $99.00
5-10 $95.00
11+ $89.00
White IN-WALL DMX RGB-W LED Controller
White IN-WALL DMX RGB-W LED Controller
SKU: SA-CTRL-INWALL-DMX-White
  • White Surface
  • 4 Channel DMX  controller (RGBW)
  • Up to 3 Savable custom colors
  • Full control of color and brightness
  • Easily select preferred color using color wheel
  • Choose from 3 different white modes: (Daylight White, Warm White, and Pure White.)
QTY Price per unit
1-4 $80.00
5-10 $70.00
11+ $60.00

Black IN-WALL DMX RGB-W LED Controller
Black IN-WALL DMX RGB-W LED Controller
SKU: SA-CTRL-INWALL-DMX-Black
  • Glossy Black  Interface
  • 4 Channel DMX  controller (RGBW)
  • Up to 3 Savable custom colors
  • Full control of color and brightness
  • Easily select preferred color using color wheel
  • Choose from 3 different white modes: (Daylight White, Warm White, and Pure White.)
QTY Price per unit
1-4 $80.00
5-10 $70.00
11+ $60.00

DMX Boss Wi-Fi Controller
DMX Boss Wi-Fi Controller
SKU: SA-CTRL-DMX-BOSS-WIFI
  • White Glass Touch Screen Interface
  • Wi-Fi Router built-in for Smartphone or Tablet Control
  • Control up to 8 different lighting zones independently or in groups
  • 4 Channel RGB-W compatible for color changing lights with separate White color
  • 10 included preset programs with color chasing option
  • Adjustable Program Speed Buttons
  • Adjustable Brightness Control Buttons
  • Color Wheel for Precise Hue Control
  • Color Creation with independent color variations
  • Easy to Use Interface
  • Up to 32 Controllable DMX Channels
QTY Price per unit
1-4 $199.00
5-10 $191.00
11+ $179.00

Pro-Wifi DMX 8 Zone LED Controller with App
Pro-Wifi DMX 8 Zone LED Controller with App
SKU: SA-CTRL-WIFI-DMX
  • Controls DMX LED Fixtures Through Phone App via Wi-Fi
  • Includes Wi-Fi Hub and Control App
  • Multiple Zone Control (Up to 8 Zones/Areas)
  • Connect Unlimited Number of DMX LED Fixtures in Each Zone
  • RJ45 Input Port for Easy Connection to Wi-fi Router
  • Push-Down Terminals for DMX Signal Output to LED Fixtures
  • Customizable and User-Friendly App Available for iOS and Android
  • Plug and Play Installation
  • Control Single-Color, Dynamic-White, Color-Changing (RGB and RGBW) LED Fixtures
QTY Price per unit
1-4 $99.00
5-10 $95.00
11+ $89.00
DMX LEDMotion 32
DMX LEDMotion 32
SKU: SA-CTRL-32
  • Includes Hardware Solution, USB 2.0 and Downloadable Software
  • Internal memory for 1 show (Stand Alone mode)
  • Software Installation Compatible with Mac OS & Windows
  • Can Control Up to 32 Zones:
    • RGB - 10 Zones
    • RGBW - 8 Zones
    • Single Color - 32 Zones
  • LED Lighting Controller with Extended Features
  • Programable & Personalize Lighting Sequences
  • Create Custom Programs with Multiple Fading Effects and Color Chases
  • Strong Aluminum Housing with Wall Mounts
  • Can be Integrated with Any LED Lighting Products
QTY Price per unit
1-4 $129.00
5-10 $123.84
11+ $116.10
DMX LEDMotion 512
DMX LEDMotion 512
SKU: SA-CTRL-252
  • Includes Software and Harware solution.
  • Internal memory for 1 show (Stand Alone mode)
  • LED Lighting Controller with Extended features
  • Personalize Endless Lighting programs with included software
  • Can control up to 170 Different Zones
  • Create programs with multiple fading effects and color chases
  • Can be integrated with any LED lighting Product
  • Optional Wireless Remote control
QTY Price per unit
1-4 $249.00
5-10 $239.00
11+ $224.00

DMX LEDMotion Stand Alone 512
DMX LEDMotion Stand Alone 512
SKU: SA-CTRL-25
  • Fully Programmable by  DMX Software
  • 1 Universe with 512 Addresses
  • Includes Easy to Use Software
  • Select Program, Speed and Brightness Through Buttons
  • Can Control Up to 170 Different Zones
  • Create Programs with Multiple Fading Effects, Color Chases and Timings
  • Set Schedules for Programs
  • Can Be Integrated with Any LED Lighting Product
  • Micro SD Card Slot for Expanded Memory Capacity
  • Right Angle Barrel Jack to Help Save Room in Installation and Hide Cable
QTY Price per unit
1-4 $349.00
5-10 $335.00
11+ $314.00
SlimDMX Stand Alone 512
SlimDMX Stand Alone 512
SKU: SA-CTRL-INWALL-DMX-SLIM
  • Modern White Gloss Surface
  • Extra Slim Design
  • Fully Programmable with included DMX Software
  • 1 Universe with 512 Addresses
  • Can be controlled by smartphone or tablet using iOS and Android
  • Included easy to use software
  • Select Program, Speed and Brightness with front buttons
  • Control up to 170 Different Zones
  • Create programs with multiple fading effects, color chases and timing
  • Set Schedules for Programs
  • Can be integrated with any LED Lighting Product
QTY Price per unit
1-4 $399.00
5-10 $384.00
11+ $360.00
24 Channel DMX-RGB LED Controller
24 Channel DMX-RGB LED Controller
SKU: SA-CTRL-011-B
  • Control up to 8 X 3 RGB LED Lights through any DMX System.
  • Create motion and show effects through its 8 outputs
  • Great For Channel Letters and Signage
  • 12-24V DC Operation
  • Up to 1A per channel 3A/ Channel in RGB Mode
  • Max 24 Amps all channels.
  • Fully DMX Addressable and incremental DMX Addressing through dip switches.
  • Detachable inputs/outputs
Price$75.00
4 Channel DMX-RGB-W LED Controller
4 Channel DMX-RGB-W LED Controller
SKU: SA-CTRL-001-V2
  • UL Listed - E493882
  • Converts DMX Signals to RGB-W
  • Stand-Alone Function with RGBW Programs
  • Easy to Use Digital Readout
  • DMX512 Compatible
  • 480W Control at 24V and 240W at 12V
  • DMX Address Selection LED Display
  • DMX IN and OUT
  • RoHs, CE Certificate
  • 12, 24, and 36 Volt Operation
  • 3 Year Warranty
  • Overheat and Over Current Protection
QTY Price per unit
1-4 $55.00
5-10 $52.00
11+ $49.00
ProAV 4 Channel DMX to RGB-W LED Controller
ProAV 4 Channel DMX to RGB-W LED Controller
SKU: SA-CTRL-DMX-RJ45-4CH
  • Converts DMX512 Signal to RGBW
  • RJ45 Input / Output Ports for Easy Cascading with Multiple Controllers
  • Quality Metal Housing with Built-in Mounting Tabs for Easy Installation
  • Crisp LED Numeric Display Screen with Buttons for Easy Configuration
  • Fully Functional On a Wide Voltage Input Range of 12V to 36V DC
  • Powerful 4 X 8A Output Channels that Drive up to 384W at 12V DC and 768W at 24V DC
  • Output Refresh Rates of 200Hz and 1500Hz, The 1500Hz Gives a Flicker-Free Performance
  • Ability to Merge all Output Channels Into One or Set Them To Use Separately
  • Linear and Logarithmic Dimming Options to Choose for Your Application
  • Easily Daisy-Chainable with Amplifiers to Create an Unlimited Output
QTY Price per unit
1-4 $59.00
5-10 $56.60
11+ $53.00
ProAv 5 Channel DMX & RDM to RGBWA Decoder
ProAv 5 Channel DMX & RDM to RGBWA Decoder
SKU: SA-CTRL-DMX-RGBWA-PROAV
  • Converts DMX Signals to RGBWA
  • Great For Audiovisual Applications
  • UL Listed Product For Safety and Durability
  • Flicker Free Output Performance
  • Bright LED Display For Easy Setup
  • Selectable 8-Bit or 16-Bit PWM Ratios
  • Adjustable PWM Frequency (500Hz - 30000Hz)
  • Fully Adjustable Micro-Dimming
  • 12-24V DC Operation
  • 5 x 8amps Channels
  • Max Power of 960W at 24V DC
QTY Price per unit
1-4 $78.00
5-10 $75.00
11+ $70.00
ProAv 12 Channel DMX & RDM to RGBW Decoder
ProAv 12 Channel DMX & RDM to RGBW Decoder
SKU: SA-CTRL-DMX-RGBW-12CH
  • DMX512 to RGBW Decoder
  • Great for Complete Flicker-Free Performance
  • Powerful 12 X 5A Output Channels That Can Run Up to 3 sets of RGBW Fixtures
  • Maximum Power Output of 720W at 12V DC and 1440W at 24V DC
  • Excellent Choice for Audiovisual Applications
  • Adjustable PWM Frequency/Refresh Rate (500Hz - 30000Hz)
  • Crisp numeric display for easy configuration
  • Selectable 8-bit or 16-bit PWM ratios for the best output resolution
  • Micro-dimming function for ultra-precise color mixing
  • Adjustable Gamma Dimming Curves to select for your specific application
  • Multiple Input/output connections including RJ45, XLR and Screw-down Terminal

QTY Price per unit
1-4 $119.00
5-10 $114.00
11+ $107.00
